TS-16 Load Cell Simulator

$491.00

TS-16 Load Cell Simulator

Simulators are used to replace a load cell to quickly check an indicator to see if the indicator is performing correctly. variety of companies produce simulators but none of them as accurate as this unit. The smoothly operating 10 turn potentiometer (V in Part Number) will vary the signal to the indicator from 0 to 3 mv/V with an excitation voltage up to 20 VDC/VAC.
TS-16 – 0, .2, .4, .6, .8, 1.0, 1.2, 1.4, 1.6, 1.8, 2.0, 2.2, 2.4, 2.6, 2.8, 3.0 mv/V
This simulator is perfect for checking set point relay operation operation on indicators used with batching systems. Wires terminate at screw type binding posts. ABS thermoplastic case.

In stock (can be backordered)

Description

TS-16 Load Cell Simulator

Simulators are used to replace a load cell to quickly check an indicator to see if the indicator is performing correctly. variety of companies produce simulators but none of them as accurate as this unit. The smoothly operating 10 turn potentiometer (V in Part Number) will vary the signal to the indicator from 0 to 3 mv/V with an excitation voltage up to 20 VDC/VAC.
TS-16 – 0, .2, .4, .6, .8, 1.0, 1.2, 1.4, 1.6, 1.8, 2.0, 2.2, 2.4, 2.6, 2.8, 3.0 mv/V
This simulator is perfect for checking set point relay operation operation on indicators used with batching systems. Wires terminate at screw type binding posts. ABS thermoplastic case.

Additional information

Weight 2.0 lbs
